Product Details:
|
Features: | Good Folding Resistance, Water Resistance | Other Name: | Clay Coated Board / Duplex Board Grey Back |
---|---|---|---|
Basic Weight: | 200 / 230 / 250 / 300 / 350 / 400 / 450 Gsm | Roll Width: | 1000mm, 1100mm, 1160mm, 1300mm, Etc |
Other Size: | Customized. Sheet Size Also OK | Material: | Recycled Wood Pulp |
Highlight: | duplex board grey back,duplex paper board |
Product description |
C1S Grey back paper |
Product name | C1S grey back paper |
Gram | 200 / 230 / 250 / 300 / 350 / 400 / 450 gsm. Above 450gsm can be laminated |
Size |
in sheet: 61 x 86 cm, 70 x 100 cm, 57 x 85 cm, 60 x 90cm in roll: 61cm, 86cm, 70cm, 100cm, 90cm, 100cm, 130cm, etc Any size can be customized as per requests |
Load QTY | 1*20ft can load 18 - 20 Tons; 1*40ft can load 25 - 26 Tons |
Sample | We provide A4 size free sample, if need large sheet or roll, pls contact us |
Technical data sheet |
C1S Grey back paper |
Properties | Unit | Gsm & Grade | |||||||
Grammage | g/m2 | 200 | 230 | 250 | 270 | 300 | 350 | 400 | 450 |
Tolerance | g/m2 | 193-210 | 220-241 | 242-260 | 260-282 | 290-315 | 290-315 | 385-415 | 428-465 |
Caliper | μm | 230±15 | 280±15 | 305±15 | 330±15 | 365±15 | 430±15 | 495±15 | 550±15 |
Moisture | % | 6.5±1.5 | 7.0±1.5 | 7.5±1.5 | 7.5±1.5 | 7.8±1.5 | 8.0±1.5 | 8.0±1.5 | 8.0±1.5 |
Stiffness(Taber) SD/MD | ≥ g.cm | 13 / 26 | 13 / 26 | 15 / 30 | 22 / 50 | 35 / 70 | 55 / 110 | 70 / 140 | 85 / 170 |
Top COBB Value | g/m2 | ≤ 50 | |||||||
Back COBB Value | g/m2 | ≤ 300 | |||||||
SD Difference of Gram | % | ≤ 3.5 | |||||||
SD Difference of Caliper | % | ≤ 3.5 | |||||||
Roughness | μm | ≤ 2.0 | |||||||
Brightness ( Top ) | % | ≥ 76 | |||||||
Folding Endurance CD | times | ≥ 12 | |||||||
Gloss (75°) | % | ≥ 35 | |||||||
Printing gloss | % | ≥ 80 | |||||||
Ply Bonding | J/m2 | ≥ 130 | |||||||
Blister Speed | m / s | ≥ 0.9 | |||||||
K & N Value | % | 23 ± 5 | |||||||
Color | L | ≥ 86.5 | |||||||
A | 0.0 ± 0.5 | ||||||||
B | -4.5 ± 0.5 | ||||||||
Dirt ≥ 0.3 mm2 | m2 | ≤ 40 | |||||||
Dirt ≥ 1.5 mm2 | m2 | ≤ 40 | |||||||
Printing | times | ≥ 2 | |||||||
CONDITIONS OF TESTING:TEMPERATURE:23±1℃,RELATIVE HUMIDITY:50±2% |
Product description |
C1S Grey back paper |
Duplex board is usually used for packaging & printing industry.
--- It can be used for calendar
--- coffee box, tissue box, shoe box, food boxes, etc.
--- For clothes plate, insole model making
Packing details |
C1S Grey back paper |
1.Sheet Packing: Plastic film and waterproof kraft paper wrapped on strong wooden pallets with four 4 angle protector)
2. Roll Packing: waterproof Kraft paper / Film wrapped outside on strong wooden pallets or without pallets.
Our company |
C1S Grey back paper |
1. Established in 2005, We have more than 10 years experience on kinds of paperboard
2. We have different grades for different application you can choose
3. the production capacity is up 10000 tons per month, and delivery time for special size is just 7-10 days
4. Main Markets are South Asia, Mid East, South America, Africa, Eastern Asia, Korea, Vietnam, Malaysia, India, South Africa, Ghana, Argentina, Turkey, etc
5. We have a good sales team, good after sale service, advanced production equipment. In Guangzhou we have two 4 layer laminated machines and die-cutting machine .
6. We can help customer to do die-cutting different sizes are okay. To save much cost, perfect cutting edges,can be used to final products (book cover) directly.
Our main products are as follows:
Click to know details | ||
Jumbo Roll Paper | woodfree offest paper | C2S Art Paper |
Washable kraft paper | Grey Chipboard | C1S art paper |
Duplex board | Tyvek paper | Stone paper |
FAQ |
C1S Grey back paper |
Q: How can I get a sample?
A: We provide A4 size sample for free, shipping cost will be paid by your side. If you have own courier account, pls advise. Or we will send via our shipping way.
If need large sheet sample, such as 70 x 100cm, or rolls, is also available. Just contact our sales for more information.
Q: How long will I get the goods after order confirm?
A: Normally 10 - 15 work days after deposit received. If you have special requirements, pls just tell us. We try best to meet you.
Q: How's your payment terms?
A: --- Mostly by T/T payment, 30% deposit before production, balance before loading
Small amount, we accept western union.
Product picture |
C1S Grey back paper |
